Innovative Heat Reuse Systems
Heat Reuse — Dual-Role Chiller & Heat Pump
Technologically advanced solutions for Data Center Heat Reuse. One System, Two Sources: Cold to the Data Hall, Heat to the City.
)and discover all the advantages of our solutions:
Ecodry 4DK
Adiabatic Cooling System
- Up to 15% less energy consumption
- Water saving up to 95%
- Safe operation without glycol down to an ambient temperature of -30 °C (-22 ˚F)
- Remote monitoring
- Improved COP up to 30%
Remote control platform
- Unique central inferface for control of the cooling system
- Easy visualization of the connected equipment
- Alarm management and history
- Multiple access levels
Dynamico DS for Technical Molding
Dynamico DS, for any Molding Application up to 90 °C. These units guarantees a significant reduction of the cycle time by increasing the heat transfer efficiency between recirculating water flow and mold cavities, thus drastically reducing the cooling time, keeping consistent the molded part quality.
- Proven Productivity Increase: at least 20%
- Lower Operating Cost (kW/part) of -12%
- Return On Investment in Short Time
- Floor Production Capacity +20%
Dynamico DY for Technical Molding and Packaging Applications
Revolutionary product designed for dynamic temperature control with on-board chiller. Dynamico allows to search and store the best mold temperature control parameters that highly reduce the Mold Cooling Time, optimizing part quality.
- It guarantees a significant reduction in cycle time
- Mold temperature control synchronized with the process
- Increased production by up to 50% due to drastic reduction in cooling time
- Intelligent use of energy consumption
- Cost-effective investment and high ROI
- Does not require mold modifications
Dynamico DY for Technical Molding and Packaging Applications
Revolutionary product designed for dynamic temperature control with on-board chiller. Dynamico allows to search and store the best mold temperature control parameters that highly reduce the Mold Cooling Time, optimizing part quality.
- It guarantees a significant reduction in cycle time
- Mold temperature control synchronized with the process
- Increased production by up to 50% due to drastic reduction in cooling time
- Intelligent use of energy consumption
- Cost-effective investment and high ROI
- Does not require mold modifications
Thermogel - TRP
Pressurized water Temperature Control Unit, designed for general plastics molding applications up to 140 °C/284 °F.
- Control of the mold temperature synchronized with the process
- High precision: +/- 0.1 °C (+/- 0.2 ˚F) of the set value
- High accessibility for easy maintenance
Machine Interactive Database
Supervision system for plant control and optimization
- Remote control of machines from everywhere
- Live data recording (all the operating parameters)
- Data stored locally, physically installed on-site
- Safe and encrypted Data transfer
Download the brochure of the cooling system Heat Reuse
DownloadSynergo Heat Reuse Systems: High-Efficiency Solution
The same Synergo modules that cool the data hall can simultaneously run in heat-pump mode, lifting rejected heat to temperatures useful for district heating or facility use — up to 95°C hot water in Heat Export Mode, or 65°C+ on standard modular-chiller heat-reuse duty. An intelligent Sequencer assigns each module's role — Chiller Mode or Heat Pump Mode — in real time, so the plant can run anywhere from 100% cooling / 0% heat recovery to 100% cooling / 100% heat recovery, without compromising the chilled-water supply to the IT load.
Key points
- Hot water supply, Heat Export Mode: Up to 95 °C
- Integral heat-reuse hot water, standard chiller: +65 °C
- Heat Export Mode maximizes heat recovery at high condensing temperatures, prioritizing thermal energy export over pure cooling efficiency when a heat off-taker is available.
- Reference Project: Simultaneous cold + hot (10 MW) and District heating supply temp. of 75 °C (Case Study: 10 MW Data Center in Denmark with 12 Frigel's Synergo)
- Regulatory Tailwind: The EU's revised Energy Efficiency Directive requires data centres above 500 kW to report energy performance, with minimum sustainability standards expected and a climate-neutral goal by 2030; centres connected to district-heat networks benefit from specific exemptions.
Performance and sustainability without compromise
ASHRAE Standards
The ASHRAE standards with the new permitted operating parameters make it possible to work within the data center with higher temperatures, so the use of Free-Cooling and different cooling technologies compared with the traditional ones becomes even more advantageous.
Hybrid Dry Coolers
In Hybrid Dry Coolers, adiabatic cooling is made possible by special adiabatic chamber with special aluminum fins which, thanks to optimum water distribution, lower the air temperature due to water evaporation. This means additional operating hours in Free-Cooling mode.
Given the new ASHRAE ranges permitted, it will undoubtedly be even more advantageous in the future to use Hybrid Dry Coolers in Data Centers in applications at increasingly high temperatures as a back-up for cooling operations with chillers.
Total modularity
1. Easily expandable at any time
The Ecodry System allows the installation of the exact capacity required at each stage of plant development.
2. Gradual implementation
Even in existing plants, installing additional units is very simple thanks to the functional and effective modularity design.
3. Exact quantification of costs by line and product
Each unit can measure and record the specific energy consumption for each product.
4. Total reliability
The extreme simplicity, reliability and redundancy of the components of the adiabatic cooling unit minimizes the possibility of plant shutdown due to failures of the cooling system, ensuring the continuity of production 24 hours a day.
Free Cooling
Free-cooling is a concept whereby ambient air is used for cooling when the ambient temperature is lower than the data hall air (direct free-cooling) or the chilled water (indirect free-cooling).
In hydronic solutions free-cooling starts when external conditions ensure even a minimum coverage of the thermal load requirements. Thanks to the application of modulating free-cooling to maximize the free external source, the percentage of free-cooling increases proportionally in relation to the temperature difference between the internal and external environments, thus notably reducing the contribution of mechanical cooling and maximizing overall system efficiency.
Free-cooling is even more effective with high water temperatures, ensuring maximized energy savings.
Minimized water footprint
Unlike traditional systems, such as the evaporative tower, this new heat dissipation technology consumes water only during periods of extreme environmental temperatures, reducing water consumption to a minimum.
Reduced risks of emissions
1. Low GWP refrigerant
The system uses a refrigerant gas with the lowest GWP available to date.
2. Risk of losses and emissions reduced to a minimum
In each unit the refrigerant gas is divided into small separate circuits, minimizing the risk of emissions in the event of leaks.
3. Without disposal of chemical additives
It does not require the disposal of chemical additives used for water treatment.
